CF Premium Vertical 22 heat pump

– Efficiency: C.O.P up to 16 under conditions Air 26°C / Water 26 °C / Humidity 80%.
– Connected: wifi control as standard via its dedicated application.
– Eco-responsible: R32 Green refrigerant for 3 times less pollution.
– Tactile: “Touch Control” screen with integrated flow rate indicator.
– Aluminium alloy bodywork.
– Automatic defrosting.
– Supplied with winter cover and Silent Bloc.

Vertical air discharge:
– Larger evaporator surface for greater efficiency.
– Noise emissions and cold air flow upwards.
– Simplified installation: no clearance constraints or discomfort for bathers due to blowing.

All seasons:
– operates efficiently from -15°C.

Ultra-quiet:
– Turbo Silence technology (Boost mode: 120% power available to start the season earlier).
– Dual rotary compressor to limit vibrations.
– 3 operating modes: Boost / Smart / Silence.

– Recommended pool volume zone A (m³): 75(1) – 105(1b).
– Recommended pool volume zone B (m³): 60(1) – 90(1b).
– Water operating range (°C) : 5 °C to 35 °C.
– Air operating range (°C) : From -15 °C to 43 °C.
– Power in Boost 120% mode (kW) : 17.5.
– Power output (kW): 14.5 C.O.P.: 4.8 – 7.3.
– Recommended flow rate (m3/h) : 8 – 10.
– Rated power (kW): 0.42 – 3.67.
– Rated current (A): 1.82 – 15.9.
– Circuit breaker curve C (A) : 30.
– Power supply: 230 V / 1 Ph / 50 Hz.
– Gas: R32 GREEN.
– Compressor: Full-Inverter.
– Electronic expansion: Yes.
– Acoustic pressure at 10 m dB(A) : 21 – 32,9.
– Hydraulic diameter: 50 mm.
– Overall package dimensions (mm) (L x W x H): 710 x 775 x 743 Net weight (kg): 88.
